Videx VR120 Vandal resistant 5 Button Audio flush speaker panel

The VR120 door panels are all 120mm wide with CALL PROGRESS LEDs for “SPEAK”, “DOOR OPEN” and “BUSY,” along with distinct audio reassurance tones to assist the visitor. Buttons are IP68 rated to guarantee the outdoor use compliance. All face plates are deep engraved with 6mm in-filled black characters to identify each button.

The VR120 face plates are attached to their back box with either 4 or 6 anti-vandal fixings, depending on panel size and options. All face plates are fitted with a purpose manufactured neoprene seal to prevent the ingress of dust and liquid. Panels are fitted with the VX2200 functional (digital) amplifier (Art.138N) Audio amplifiers and microphones are protected with a fine offset stainless steel mesh to protect against vandalism.

All speakers have Mylar cones to further protect against the effects of moisture. Full control of volume levels to the amplifier and the telephones can be adjusted independently at the amplifier module, as can additional features including speech time, lock release time and reassurance volume etc.

Flush boxes are standard. Stainless steel bezel flush boxes and surface boxes with rainshield are also available across the full range.

Features

• 12 Gauge stainless steel
• IP68 rated buttons with optional yellow bezel
• SPEAK, BUSY & OPEN call progress LED’s
• Call progress reassurance tones
• Dry contact lock output
• Timed call, speech and lock release
• Speaker and microphone volume adjustments
